Hikvision DS-K1102AM Mifare Card Reader

The Hikvision DS-K1102AM Mifare Card Reader is a professional access control device designed for secure and efficient door entry management in offices, residential apartments, commercial buildings, institutions, and restricted areas in Kenya. It is used to read 13.56 MHz Mifare smart cards and transmit authentication data to an access control controller for safe door unlocking and user verification. Built with a compact industrial-grade design, stable communication interfaces, tamper protection, and fast processing capability, the DS-K1102AM ensures reliable and consistent performance in modern access control systems. Its durable construction, low power consumption, and wide compatibility make it suitable for both small and large-scale security installations.

Product Features

Mifare Smart Card Authentication

Supports 13.56 MHz Mifare contactless smart card technology, enabling secure and fast user identification for controlled access environments.

High-Speed Card Processing

Equipped with a fast internal processor that ensures quick card reading and immediate response for smooth entry operations.

RS-485 and Wiegand Communication Support

Supports RS-485 and Wiegand (W26/W34) interfaces for easy integration with Hikvision and third-party access control systems.

Tamper Alarm Protection

Includes built-in tamper detection that triggers an alert if the device is opened, removed, or interfered with, improving system security.

LED Status Indicators

Features LED indicators that display power status and working condition for clear system monitoring.

Built-In Audible Buzzer

Provides sound feedback during card reading to confirm successful or failed authentication attempts.

Stable and Reliable Performance

Designed for continuous operation in access control environments with consistent and dependable performance.

Durable Industrial Design

Built using strong ABS and PC materials to ensure long-lasting durability in indoor and semi-protected installations.

Easy Installation Setup

Supports standard wall mounting and back box installation for quick and convenient deployment.

DIP Switch Configuration

Allows easy device addressing and setup using DIP switch settings for system integration.

Low Power Consumption

Engineered for energy-efficient operation, ensuring stable long-term use with minimal power usage.

Product Specifications

• Brand: Hikvision
• Model: DS-K1102AM
• Product Type: Mifare Card Reader
• Card Type: 13.56 MHz Mifare smart card
• Reading Frequency: 13.56 MHz
• Reading Range: Up to 50 mm
• Processor: 32-bit high-speed processor
• Communication Interfaces: RS-485, Wiegand (W26/W34)
• Power Supply: 12V DC
• Power Consumption: ≤ 2W
• Working Current: ≤ 500 mA
• Indicators: LED status indicators
• Audio Output: Built-in buzzer
• Tamper Protection: Supported
• Installation Type: Wall-mounted (standard back box compatible)
• Housing Material: ABS + PC durable casing
• Operating Temperature: -20°C to 65°C
• Operating Humidity: 10% to 90% (non-condensing)
• Protection Level: IP64 dust and splash resistance
• Application: Access control systems for residential, commercial, and institutional buildings
