DAHUA DH-HDW1230T2-A Dome 2MP (3.6 mm) Camera

The DAHUA DH-HDW1230T2-A Dome 2MP (3.6 mm) Camera is a Full HD fixed-focal network surveillance camera designed for homes, offices, retail shops, schools, and small business CCTV installations that require dependable indoor and outdoor monitoring. Equipped with a 2MP CMOS image sensor, this Dahua IP camera records at 1920 × 1080 resolution for clear video capture across entrances, corridors, reception areas, cashier points, and perimeter access zones. It supports H.265 video compression for efficient storage and bandwidth use, features infrared night vision up to 30 meters, includes a built-in microphone for audio recording, and offers DWDR image enhancement, 3D noise reduction, and IP67 weather-resistant protection, making it a practical security camera for round-the-clock surveillance.

Product Features

2MP Full HD Video Recording
The 2MP CMOS image sensor captures clear 1080p Full HD video, helping deliver reliable surveillance footage for daily monitoring in homes, offices, retail stores, schools, and commercial spaces where image clarity is important for viewing activity and movement.

3.6 mm Fixed Lens for Focused Coverage
This camera comes with a 3.6 mm fixed lens, making it suitable for monitoring specific areas such as doors, hallways, counters, office entrances, and small outdoor spaces. It provides a practical field of view for installations that require a stable viewing angle.

Infrared Night Vision up to 30 Meters
With IR night vision up to 30 meters, the camera can continue recording visible footage in low-light and night conditions. This makes it suitable for 24-hour surveillance in corridors, exteriors, entry points, and other areas that need continuous monitoring.

Built-In Microphone for Audio Recording
The built-in microphone allows the camera to record audio together with video, adding extra context to surveillance footage in areas such as reception desks, front office spaces, cashier points, and shop entrances where audio monitoring is needed and permitted.

H.265 Compression for Efficient Storage
Support for H.265 and H.264 compression, including smart compression technology, helps reduce storage requirements and network bandwidth usage while maintaining effective recording performance. This is useful for CCTV systems that need longer recording times and efficient video management.

Image Enhancement for Better Clarity
The camera includes DWDR, BLC, HLC, 3D noise reduction, and ROI, helping improve image quality in scenes with backlight, glare, shadows, and uneven lighting. These features support better visibility and more consistent surveillance footage.

IP67 Weather-Resistant Housing
Its IP67-rated housing helps protect the camera against dust and rain, making it suitable for both indoor and outdoor CCTV installation. It can be installed in exposed areas such as building entrances, shop exteriors, verandas, and perimeter walls.

Product Specifications

• Brand: Dahua
• Model: DH-HDW1230T2-A
• Product Type: 2MP IR Fixed-Focal Dome / Eyeball Network Camera
• Image Sensor: 2MP CMOS
• Maximum Resolution: 1920 × 1080
• Lens:6 mm fixed lens
• Video Compression:265, H.264, Smart H.265+, Smart H.264+
• Night Vision: Infrared illumination up to 30 meters
• Audio: Built-in microphone
• Image Features: DWDR, BLC, HLC, 3D NR, ROI, rotation mode, digital watermarking
• Event Functions: Motion detection, video tampering, audio detection, network disconnection, IP conflict, illegal access
• Network Port: RJ-45 10/100 Mbps Ethernet
• Power Supply: 12V DC / PoE
• Weather Protection: IP67
• Installation Use: Indoor and outdoor CCTV surveillance
• Application Areas: Homes, offices, shops, schools, corridors, receptions, and perimeter monitoring
