Ubiquiti UniFi Protect G5 Dome Ultra 2K PoE Security Camera, Black (UVC-G5-Dome-Ultra-B)

Ubiquiti UniFi Protect G5 Dome Ultra UVC-G5-Dome-Ultra-B is a compact 2K PoE security camera designed for discreet indoor video surveillance. It features a 4MP image sensor that captures video at up to 2688 x 1512 resolution and 30 frames per second, delivering clear and detailed footage for monitoring homes, offices, retail stores, reception areas, corridors, and other indoor spaces. Its 102.4° horizontal field of view provides broad coverage, while integrated infrared illumination enables night vision up to 20m. The camera also supports UniFi Protect smart detections for people, vehicles, and animals, and uses a single PoE Ethernet connection for both power and data. Its compact black dome housing features IK06 impact resistance and a low-profile design suitable for discreet security installations.

Product Features

2K 4MP Video Quality

The G5 Dome Ultra captures detailed 4MP surveillance footage at a maximum resolution of 2688 x 1512 pixels and up to 30 frames per second, providing clear video for security monitoring and incident review.

Wide-Angle 102.4° Field of View

The fixed lens provides a 102.4° horizontal field of view, allowing the camera to monitor a broad area while maintaining a compact installation footprint.

Infrared Night Vision

Integrated infrared illumination provides night vision coverage up to 20m, allowing the camera to continue monitoring in dark or low-light environments.

AI-Powered Smart Detection

UniFi Protect smart detection capabilities can identify people, vehicles, and animals, helping distinguish relevant activity from general movement and improving event monitoring.

Compact Dome Design

The ultra-compact dome housing measures approximately 63.6mm in diameter, making it suitable for discreet installations where space and appearance are important considerations.

PoE Connectivity

Power and network data are delivered through a single Ethernet cable using Power over Ethernet, simplifying installation and eliminating the need for a separate power cable at the camera.

UniFi Protect Integration

The camera integrates with the UniFi Protect platform for centralized video surveillance management, live viewing, recording, camera configuration, and smart event monitoring.

IK06 Impact Resistance

The camera enclosure is rated IK06 for impact resistance and combines aluminum alloy and polycarbonate construction for added physical durability.

Flexible Mounting

The camera includes a surface mounting option and supports optional mounting accessories for applications requiring junction box or ultra-flush installation.

Low Power Consumption

With maximum power consumption of approximately 4.2W, the camera is suitable for installations requiring efficient PoE-powered surveillance equipment.

Advanced Image Controls

The camera supports multiple image adjustment options, including brightness, contrast, sharpness, color, white balance, and exposure. Noise reduction and privacy masking features further support professional surveillance deployments.

Indoor Surveillance

The compact design makes the G5 Dome Ultra suitable for indoor security applications including residential properties, offices, shops, commercial buildings, reception areas, hallways, and other controlled environments.

Product Specifications

• • Product model: UVC-G5-Dome-Ultra-B
  • Product family: UniFi Protect
  • Product type: Fixed dome IP security camera
  • Camera color: Black
  • Video resolution: 2K
  • Effective resolution: 4MP
  • Maximum resolution: 2688 x 1512 pixels
  • Maximum frame rate: 30 FPS
  • Aspect ratio: 16:9
  • Image sensor: 1/2.4-inch CMOS
  • Lens type: Fixed focal length
  • Horizontal field of view: 102.4°
  • Vertical field of view: 54.9°
  • Diagonal field of view: 120.6°
  • Night vision: Yes
  • IR illumination: Built-in infrared LED
  • IR night vision range: Up to 20m
  • IR cut filter: Yes
  • Smart detections: People, vehicles, and animals
  • Network interface: 1 x 10/100 MbE RJ45 Ethernet port
  • Wireless connectivity: None
  • Power method: PoE
  • Supported input voltage: 37-57V DC
  • Maximum power consumption: 4.2W
  • Processor: Dual-core Arm Cortex-A7 based processor
  • Enclosure material: Aluminum alloy and polycarbonate
  • Mount material: Stainless steel
  • Impact resistance: IK06
  • Included mounting: Surface mount
  • Optional mounting: Junction box and ultra-flush mount
  • Factory reset: Reset button
  • Dimensions: 63.6 x 68.2mm
  • Weight: 175g
  • Operating temperature: -20°C to 40°C
  • Operating humidity: 10% to 90%, non-condensing
  • Image controls: Color, brightness, sharpness, contrast, white balance, and exposure
  • Noise reduction: 2D noise reduction, 3D noise reduction, and motion-based noise reduction
  • Privacy features: Privacy masking and text overlay
  • Management platform: UniFi Protect
  • NDAA compliant: Yes
  • Certifications: CE, FCC, and IC
  • Recommended installation: Indoor
  • Manufacturer: Ubiquiti
