Ubiquiti NanoStation 5AC Loco (UISP-Ready) 5 GHz airMAX AC Wireless Radio

The Ubiquiti NanoStation 5AC Loco is a compact 5 GHz outdoor wireless radio designed for reliable point-to-point and point-to-multipoint wireless networking, broadband connectivity, CCTV links, and network extension applications. Featuring Ubiquiti airMAX AC technology and an integrated 13 dBi dual-linear polarized antenna, it provides focused wireless performance in a lightweight and easy-to-install design. The NanoStation 5AC Loco includes a Gigabit Ethernet interface, supports Access Point and Station modes, offers channel bandwidths up to 80 MHz, and is UISP-ready for centralized network management, making it suitable for professional outdoor wireless deployments.

Product Features

5 GHz airMAX AC Technology

The NanoStation 5AC Loco uses Ubiquiti airMAX AC technology to provide efficient wireless connectivity for outdoor broadband networks, wireless bridges, and professional networking applications.

Integrated 13 dBi Directional Antenna

The built-in 13 dBi dual-linear polarized antenna provides focused wireless coverage and is optimized for directional point-to-point and point-to-multipoint deployments.

UISP-Ready Management

The NanoStation 5AC Loco is UISP-ready, allowing compatible networks to be monitored and managed through Ubiquiti’s UISP platform for centralized administration and network visibility.

Gigabit Ethernet Connectivity

A Gigabit RJ45 Ethernet port provides high-speed wired connectivity between the wireless radio and the connected network. The Ethernet interface also supports passive PoE power delivery.

Access Point and Station Modes

The device supports Access Point and Station operating modes, allowing it to be configured for different wireless network architectures and link requirements.

Adjustable Channel Bandwidth

Channel bandwidth options from 10 MHz through 80 MHz provide flexibility when configuring wireless links according to available spectrum, network capacity, and deployment requirements.

Outdoor-Ready Construction

The NanoStation 5AC Loco features a UV-stabilized polycarbonate enclosure and is designed to operate in temperatures ranging from -40°C to 70°C, making it suitable for demanding outdoor installations.

Compact Pole-Mount Installation

Its compact 179 x 77.5 x 59.1 mm enclosure and 180 g weight make the NanoStation 5AC Loco easy to position and install. A pole-mounting system is included for outdoor deployments.

Wireless Signal Indicators

Integrated LED indicators provide visual status information for power, Ethernet connectivity, and wireless signal strength, helping installers align and troubleshoot the device.

Professional Network Management

The device provides management features including DHCP, bridging, routing, SNMP, SSH, web-based management, ping watchdog, QoS, traffic shaping, and statistical reporting.

Product Specifications

• Brand:Ubiquiti
• Product Name:NanoStation 5AC Loco
• Model:Loco5AC
• Product Type:5 GHz airMAX AC outdoor wireless radio
• Management:UISP-ready
• Wireless Technology:airMAX AC
• Operating Modes:Access Point, Station
• Frequency Range:5150-5875 MHz
• Antenna Gain:13 dBi
• Antenna Type:Integrated dual-linear polarized antenna
• Horizontal Beamwidth:45°
• Vertical Beamwidth:45°
• Elevation Beamwidth:45°
• Cross-Polarization Isolation:Minimum 20 dB
• Maximum VSWR:8:1
• Channel Bandwidths:10, 20, 30, 40, 50, 60, and 80 MHz
• Ethernet Interface:1 x Gigabit RJ45 Ethernet port
• Power Method:Passive PoE, 2-pair
• Operating Voltage:22-27V DC
• Maximum Power Consumption:7W
• Recommended PoE Supply:24V, 0.3A Gigabit PoE supply
• PoE Supply Included:No
• Dimensions:179 x 77.5 x 59.1 mm
• Weight:180 g
• Enclosure Material:UV-stabilized polycarbonate
• Mounting:Pole mount
• Operating Temperature:-40°C to 70°C
• Operating Humidity:5% to 95%, non-condensing
• LED Indicators:Power, Ethernet, signal strength
• Network Management:DHCP, bridging, routing, SNMP, SSH, web server, ping watchdog, QoS, traffic shaping, statistical reporting
• Typical Applications:Point-to-point wireless links, point-to-multipoint networks, outdoor broadband, CCTV connectivity, wireless network extension, and ISP deployments
• Compliance:NDAA compliant
• Certifications:CE, FCC, IC, Anatel 01405-19-08356
• Power Supply Note:The recommended 24V, 0.3A Gigabit PoE supply is not included and may need to be purchased separately.
