Hikvision NVR-104MH-D/4P Network Video Recorder Kenya | 4-Channel PoE 4K Lite H.265 NVR

The Hikvision NVR-104MH-D/4P is a compact 4-channel network video recorder designed for small IP CCTV systems that require simple installation, reliable recording, and built-in Power over Ethernet (PoE). It is commonly used in homes, small offices, shops, and basic commercial surveillance setups where a stable plug-and-play IP camera system is needed. With H.265+ compression and support for up to 4 IP cameras, it delivers efficient storage usage and smooth HD video recording while reducing network and bandwidth load.

Product Features

4-channel IP camera support

The NVR supports up to 4 IP cameras, making it ideal for small surveillance systems such as homes, retail shops, and small offices that require focused security coverage.

Built-in 4-port PoE switch

It includes 4 PoE ports that directly power compatible IP cameras through Ethernet cables, eliminating the need for separate power supplies and simplifying installation.

H.265+ video compression technology

Advanced H.265+ compression reduces storage requirements and bandwidth usage while maintaining clear and stable video recording quality.

Supports up to 6MP camera input

The recorder is capable of handling IP cameras up to 6 megapixel resolution, allowing high-definition surveillance with detailed image clarity.

HDMI and VGA simultaneous output

Provides full HD display output via HDMI and VGA ports, allowing connection to monitors for live view and playback.

Remote viewing and mobile access

Supports remote monitoring through mobile applications and network connection, enabling users to view live or recorded footage from anywhere.

Smart bandwidth management

Optimized network performance allows smooth video streaming even when multiple cameras are connected and recording simultaneously.

Compact and efficient design

The mini 1U design saves space and is suitable for small installation environments such as home cabinets or small security racks.

Product Specifications

• Model: NVR-104MH-D/4P
• Brand: Hikvision (HiLook series)
• Channels: 4 IP camera inputs
• PoE ports: 4 built-in PoE interfaces
• Video compression: H.265+, H.265, H.264+, H.264
• Incoming bandwidth: Up to 40 Mbps
• Outgoing bandwidth: Up to 60 Mbps
• Supported camera resolution: Up to 6MP
• Decoding capability: Up to 4-ch 1080p
• Video output: HDMI and VGA simultaneous output
• Storage: 1 SATA interface, supports up to 6TB HDD
• Network interface: 1 × RJ45 10/100 Mbps
• USB ports: 2 × USB 2.0
• Remote users: Up to 16 users
• Power supply: 48V DC, 1A
• Power consumption: ≤ 10W (without HDD and PoE load)
• Operating temperature: -10°C to +55°C
• Operating humidity: 10% to 90%
• Dimensions: 265 × 225 × 48 mm
• Weight: ≤ 1 kg (without HDD)
• Application: Small homes, shops, offices, and basic IP CCTV surveillance systems
