EZVIZ CS-TY1 4MP Smart Wi-Fi Pan and Tilt Indoor Security Camera

The EZVIZ CS-TY1 4MP Smart Wi-Fi Pan and Tilt Indoor Security Camera is an intelligent surveillance solution designed for homes, offices, shops, and small businesses. Featuring a high-resolution 4MP sensor, 360-degree panoramic coverage, human motion detection, auto-tracking, and two-way audio, this camera provides clear and reliable indoor monitoring. With advanced H.265 video compression, infrared night vision, and remote access through the EZVIZ App, the CS-TY1 4MP delivers enhanced security and convenient monitoring from anywhere.

Product Features

4MP High-Resolution Video

Captures ultra-clear footage at a maximum resolution of 2560 × 1440, delivering detailed images and improved visibility for effective indoor surveillance.

360-Degree Pan and Tilt Coverage

Features motorised pan and tilt functionality that provides comprehensive room coverage and minimises blind spots for complete monitoring.

Intelligent Human Motion Detection

Uses smart detection technology to identify human movement and send instant alerts to connected devices, reducing unnecessary notifications.

Auto-Tracking Function

Automatically follows moving subjects within its field of view, helping users keep important activities in sight.

Infrared Night Vision

Provides clear black-and-white night vision up to 10 metres, ensuring dependable surveillance in low-light and complete darkness.

Two-Way Audio Communication

Includes a built-in microphone and speaker that allow users to communicate remotely with family members, visitors, or employees through the EZVIZ mobile application.

Advanced H.265 Video Compression

Reduces bandwidth usage and storage requirements while maintaining high-quality video recording and playback.

Flexible Storage Options

Supports MicroSD cards of up to 256GB, providing convenient local storage for recorded footage and playback.

Privacy Protection Mode

Features a sleep mode that temporarily disables monitoring whenever additional privacy is required.

Product Specifications

• Product Type: Smart Wi-Fi Pan and Tilt Indoor Security Camera
• Brand: EZVIZ
• Model: CS-TY1 (4MP, WI)
• Camera Resolution: 4MP (2560 × 1440)
• Image Sensor: 1/3-inch Progressive Scan CMOS
• Lens: 4mm fixed lens
• Viewing Angle: 124° diagonal, 85° horizontal, 55° vertical
• Video Compression: H.265 and H.264
• Pan and Tilt Function: 360-degree panoramic coverage
• Smart Features: Human motion detection and auto-tracking
• Night Vision Range: Up to 10 metres
• Audio: Two-way audio communication
• Storage: MicroSD card support up to 256GB
• Network Connectivity: 2.4GHz Wi-Fi and RJ45 Ethernet port
• Power Interface: Micro USB
• Power Supply: DC 5V/2A
• Power Consumption: Maximum 5W
• Operating Temperature: -10°C to 45°C
• Installation Type: Desktop or ceiling mounted
• Application: Home, office, retail, and indoor business surveillance
• Mobile Support: EZVIZ App for Android and iOS
• Maintenance Requirement: Low maintenance
• Purpose: Indoor security monitoring and remote surveillance
