HIKVISION DS-1LN6AUSPE CAT6A U/UTP OUTDOOR NETWORK CABLE 305M

The Hikvision DS-1LN6AUSPE is a Cat6A U/UTP outdoor network cable designed for high-performance data transmission in advanced CCTV systems, enterprise networking, and outdoor structured cabling installations. It is engineered with solid bare copper conductors to deliver superior signal integrity, reduced attenuation, and stable performance for high-speed Ethernet and Power over Ethernet (PoE) applications. The cable is widely used in Kenya for IP surveillance systems, long-distance network deployment, and industrial connectivity projects where durability and consistent transmission quality are required. Its rugged PE jacket and enhanced electrical performance make it suitable for outdoor environments and demanding installation conditions.

Product Features

Cat6A high-speed network performance

The cable supports Cat6A standards, enabling stable high-bandwidth data transmission suitable for Gigabit and 10-Gigabit Ethernet applications, making it ideal for modern surveillance and enterprise networks.

Solid bare copper conductor construction

It uses 23 AWG solid bare copper conductors that provide low resistance, improved conductivity, and reliable long-distance signal stability compared to copper-clad alternatives.

Outdoor-rated durable PE jacket

The outer sheath is made of strong polyethylene material designed for outdoor use, offering resistance against environmental stress, moisture, and mechanical damage during installation.

Enhanced PoE compatibility

The DS-1LN6AUSPE supports Power over Ethernet transmission with stable performance under continuous load, making it suitable for powering IP cameras and network devices over long distances.

Reduced crosstalk and interference

Its twisted pair structure is optimized to reduce alien crosstalk and electromagnetic interference, ensuring clean and stable signal transmission in dense cable environments.

High mechanical strength design

The cable is built with strong tensile and compressive resistance, reducing the risk of damage during pulling, installation, and long-term use in structured cabling projects.

Stable long-distance transmission

Designed for reliable performance over extended runs, it maintains signal quality within Cat6A standards, making it suitable for large buildings, campuses, and outdoor installations.

Compliance with international standards

It meets key standards including ANSI/TIA-568.2-D, ISO/IEC 11801, and RoHS 2.0, ensuring compatibility with modern networking equipment and structured cabling systems.

Product Specifications

• Model: DS-1LN6AUSPE
• Cable Type: Cat6A U/UTP outdoor network cable
• Conductor Material: Solid bare copper (99.95% purity)
• Conductor Size: 23 AWG (0.565 ± 0.005 mm)
• Cable Structure: U/UTP (Unshielded Twisted Pair)
• Jacket Material: PE (Polyethylene), outdoor rated
• Cable Length: 305 meters per roll
• Frequency Performance: Up to 500 MHz
• Impedance: 100 ± 15 ohms
• DC Resistance: ≤ 9.38 ohms per 100 meters
• Operating Voltage: Up to 80 V
• Installation Temperature Range: -20°C to 75°C
• Storage Temperature Range: -40°C to 75°C
• Structural Elements: Includes rip cord and internal separator
• Standards Compliance: ANSI/TIA-568.2-D, ISO/IEC 11801, RoHS 2.0
• Application: Outdoor CCTV systems, IP surveillance networks, enterprise LAN cabling, PoE installations, industrial networking projects
