Hikvision DS-3E0524-E 24-Port Gigabit Unmanaged Network Switch

The Hikvision DS-3E0524-E 24-Port Gigabit Unmanaged Network Switch is a high-capacity, enterprise-grade networking device designed to deliver fast, stable, and efficient wired connectivity for offices, institutions, businesses, cyber cafés, surveillance systems, and large-scale home networks in Kenya. Equipped with 24 Gigabit Ethernet RJ45 ports, this unmanaged switch supports high-speed data transmission suitable for demanding applications such as HD and 4K IP CCTV systems, server connections, large file transfers, and seamless internet sharing across multiple devices. Its plug-and-play design allows easy installation without configuration, making it ideal for both professional installers and general users.

Built with durability and performance in mind, the DS-3E0524-E features a strong metal housing that enhances heat dissipation and ensures reliable long-term operation in continuous-use environments. The fanless design contributes to silent operation while improving system reliability by eliminating moving parts. With non-blocking switching architecture, intelligent store-and-forward processing, and automatic MAC address learning, the switch ensures smooth and stable data flow between all connected devices without congestion.

The DS-3E0524-E is suitable for expanding high-speed wired networks where consistent Gigabit performance is required. It supports stable connectivity for network video recorders, IP cameras, computers, routers, access points, printers, and other Ethernet-enabled devices. Its rack-mountable design makes it ideal for structured network installations in server rooms, offices, schools, and commercial environments.

Designed with energy-efficient operation and built-in surge protection, this Hikvision switch helps reduce power consumption while protecting connected equipment from electrical fluctuations. It provides a reliable backbone for modern networking infrastructures requiring speed, stability, and scalability.

Product Features

24 Gigabit Ethernet Ports

The switch includes 24 RJ45 ports supporting 10/100/1000 Mbps auto-negotiation, providing high-speed wired connectivity for multiple devices within a single network.

Plug-and-Play Network Setup

The unmanaged design allows immediate deployment without requiring software installation, configuration, or technical network setup.

High-Speed Data Transmission

Gigabit switching capability ensures fast and stable data transfer suitable for bandwidth-heavy applications such as surveillance systems and enterprise networking.

Reliable CCTV and Business Networking

The switch provides stable connectivity for IP surveillance systems, office networks, and multi-device environments requiring consistent performance.

Durable Metal Housing Construction

The metal casing enhances structural durability and improves heat dissipation for continuous 24/7 operation in demanding environments.

Silent Fanless Operation

The fanless cooling system ensures noise-free performance, making it suitable for indoor office and commercial installations.

Stable Switching Performance

Store-and-forward technology ensures accurate packet delivery while reducing errors and maintaining network stability.

Auto-Negotiation Support

Each port automatically detects and adjusts to the optimal speed of connected devices for efficient communication.

Auto MDI/MDIX Functionality

The switch automatically adjusts cable detection, eliminating the need for crossover cables during installation.

Energy-Efficient Operation

Low power consumption design helps reduce electricity usage while maintaining high network performance.

Rack-Mount Installation Design

The 1U rack-mountable structure allows structured installation in server racks and network cabinets.

Built-In Surge Protection

Integrated surge protection helps safeguard connected devices against electrical spikes and voltage fluctuations.

Product Specifications

• Brand: Hikvision
• Model: DS-3E0524-E
• Product Type: Unmanaged Gigabit Ethernet Switch
• Ports: 24 × 10/100/1000 Mbps RJ45
• Port Type: Gigabit Ethernet
• Switching Capacity: 48 Gbps
• Packet Forwarding Rate: 35.71 Mpps
• MAC Address Table: 8K
• Transmission Method: Store-and-Forward
• Network Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Port Features: Auto Negotiation, Auto MDI/MDIX
• Housing Material: Metal
• Cooling System: Fanless
• Installation Type: Rack Mount (1U)
• Power Supply: AC 100–240 V, 50/60 Hz (External/Integrated Power System depending on variant)
• Maximum Power Consumption: 18 W
• Idle Power Consumption: 3.8 W
• Surge Protection: 6 kV
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 85°C
• Operating Humidity: 5% to 95% Non-Condensing
• Dimensions: 440 × 44 × 160 mm
• Weight: 1.4 kg
• Color: Black
• Ethernet Cable Support: Cat5, Cat5e, Cat6
• Management Type: Unmanaged
• Usage Environment: Indoor Use Only
